    Hydrostatic Sensor Paver Main Image
    Industrial Standard

    FOR TARPAULIN

    FOR TARPAULIN is a specialized industrial solution designed to enhance efficiency and consistency in tarpaulin manufacturing and processing applications. Developed with precision engineering and durable construction, it ensures smooth operation, high productivity, and reliable performance in demanding industrial environments. This solution is ideal for industries producing HDPE and plastic tarpaulins used in agriculture, construction, transportation, and storage applications. It supports uniform processing, improved output quality, and optimized workflow across production lines.

    Explore Machine Details
    [ 01 ] technical specification

    10 TON

    Machine Specification
    Structure Specification
    Main Structure Plate 8mm
    Cylinder Mounting Plate 16mm
    Pillar Box Pipe 100 X 50 X 5mm
    Machine Specification
    Capacity 10 Ton
    Platform Size (mm) 800 X 600
    Bale Size (mm) L X W X H 800 X 600 X 300
    (Height Will be change as per Material Density)
    Pressing Material Tarpaulin
    Pressure (Kg/cm²) 100
    Cylinder Size (Bore-Ram-Stroke) mm 60 – 100 – 900
    Daylight Gap (mm) 1050
    Minimum Gap (mm) 150
    Electric Motor (HP) 5 HP
    Cycle Time (Sec) 20 - 25
    Guide Rod Details Dia. 40mm, Length 1250mm, 2 Nos.
    Pump Type Hydraulic Gear Pump
    Pump Output 27 LPM
    Control System By Panel (Start, Stop, Up, Down, Emergency)
    Connecting Load • Motor Load: 5 HP / 3.75 Kw (440 V, 50 Hz)
    • Limit Switches: (220 V, 50 Hz)
    Oil Required 150 LTR (Grade 68 No.) Buyer Scope
    Machine Finishing 2 Primer Coat + 2 Paint Coat
    Standard Color of Paint will be Deep Orange
    Bought Out Item Details
    Main Motor
    Brand Bharat Bijli / Crompton
    Speed 1440 RPM
    Mounting Type Vertical, Flange Mount
    Operating on 440 V, 50 Hz
    Type Non Flame Proof
    Power Pack Details (Mech Heart Machineries Private Limited)
    Oil Pump
    Pump Type Gear Pump
    Pump Output 27 LPM
    Mounting Type Vertical
    Coupled with Motor By Nylon Coupling
    Brand Colt
    Direction Control Valve
    Brand Polyhydron
    Operated By Hand Lever
    Operated on Manual Hand Lever
    Pressure Gauge
    Size 4 Inch
    Filled Glycerin Filled
    Mounting Side At Top, Back Side Clamp Mount
    Other Components
    M.S. Manifold Standard as per Power Pack
    Filter Standard as per Power Pack
    Flexible Hose Pipe Standard as per Power Pack
    Hydraulic Feedings Standard as per Power Pack
    Other Accessories Standard as per Power Pack

    [ 01 ] technical specification

    20 TON

    Machine Specification
    Structure Specification
    Main Structure Plate 8mm
    Cylinder Mounting Plate 16mm
    Pillar Box Pipe 100 X 50 X 5mm
    Machine Specification
    Capacity 20 Ton
    Platform Size (mm) 1200 X 800
    Bale Size (mm) L X W X H 1200 X 800 X 450
    (Height Will be change as per Material Density)
    Pressing Material Tarpaulin
    Pressure (Kg/cm²) 100
    Cylinder Size (Bore-Ram-Stroke) mm 90 - 120 - 1000
    Daylight Gap (mm) 1150
    Minimum Gap (mm) 150
    Electric Motor (HP) 7.5
    Cycle Time (Sec) 20 - 25
    Guide Rod Details Dia. 40mm, Length 1250mm, 2 Nos.
    Pump Type Hydraulic Gear Pump
    Pump Output 40 LPM
    Control System By Panel (Start, Stop, Up, Down, Emergency)
    Connecting Load Motor Load: 7.5 HP / 5.6 Kw (440 V, 50 Hz)
    Limit Switches (220 V, 50 Hz)
    Direction Control Valve (220 V, 50 Hz)
    Oil Required 150 LTR (Grade 68 No.) Buyer Scope
    Machine Finishing 2 Primer Coat + 2 Paint Coat
    Standard Color: Deep Orange
    Bought Out Item Details
    Main Motor
    Brand Bharat Bijli / Crompton
    Speed 1440 RPM
    Mounting Type Vertical, Flange Mount
    Operating on 440 V, 50 Hz
    Type Non Flame Proof
    Power Pack Details (Mech Heart Machineries Private Limited)
    Pump Type Gear Pump
    Pump Output 40 LPM
    Mounting Type Vertical
    Coupled with Motor By Nylon Coupling
    Brand Colt
    Direction Control Valve
    Brand Hydrank
    Operated By Solenoid
    Operated on AC 220 V
    Pressure Gauge
    Size 4 Inch
    Filled Glycerin Filled
    Mounting Side At Top, Back Side Clamp Mount
    Other Accessories
    M.S. Manifold Standard as per Power Pack
    Filter Standard as per Power Pack
    Flexible Hose Pipe Standard as per Power Pack
    Hydraulic Feedings Standard as per Power Pack
    Other Accessories Standard as per Power Pack
